Home  >  HVAC/R Components  >  Fan Blades  >  3 Fixed Wing  > 18" 3W 27 DEG CW 1/2' HUB

18" 3W 27 DEG CW 1/2' HUB

Diameter (in.) 18 Type Fixed Hub No. of Blades 3 Bore Diameter (in.) 1/2 Pitch (Degree) 27 Rotation CW Material Aluminum Max. RPM 1140 Depth (in.) 4 5/16 CFM @ 0.000-In. SP 2790 Min. HP @ 0.000-In. SP 0.1507 CFM @ 0.300-In. SP 1829 Min. HP @ 0.300-In. SP 0.21
Item #: 40340

Standard Pack: 2
Must order in multiples of: 2
18

Fixed Hub Fan Blades

  • High strength aluminum alloy
  • Designed for lower static pressure applications
  • 1/2 in. hub
  • Fits many OEM's

Fan Blades

Diameter (in.)
18
Type
Fixed Hub
No. of Blades
3
Bore Diameter (in.)
1/2
Pitch (Degree)
27
Rotation
CW
Material
Aluminum
Max. RPM
1140
Depth (in.)
4 5/16
CFM @ 0.000-In. SP
2790
Min. HP @ 0.000-In. SP
0.1507
CFM @ 0.300-In. SP
1829
Min. HP @ 0.300-In. SP
0.21
