Home  >  HVAC/R Components  >  Fan Blades  >  3 Fixed Wing  > 14" 3W 32 DEG CW DIS

14" 3W 32 DEG CW DIS

Diameter (in.) 14 Type Fixed Hub No. of Blades 3 Bore Diameter (in.) 1/2 Pitch (Degree) 32 Rotation CW Material Aluminum Max. RPM 1725 Depth (in.) 3 37/64 CFM @ 0.000-In. SP 2077 Min. HP @ 0.000-In. SP 0.2823 CFM @ 0.300-In. SP 1787 Min. HP @ 0.300-In. SP 0.3069
Item #: 40328

Standard Pack: 2
Must order in multiples of: 2
14

Fixed Hub Fan Blades

  • High strength aluminum alloy
  • Designed for lower static pressure applications
  • 1/2 in. hub
  • Fits many OEM's

Fan Blades

Diameter (in.)
14
Type
Fixed Hub
No. of Blades
3
Bore Diameter (in.)
1/2
Pitch (Degree)
32
Rotation
CW
Material
Aluminum
Max. RPM
1725
Depth (in.)
3 37/64
CFM @ 0.000-In. SP
2077
Min. HP @ 0.000-In. SP
0.2823
CFM @ 0.300-In. SP
1787
Min. HP @ 0.300-In. SP
0.3069
