SUPER-FIT FAN CENTER
Transformer Primary Voltage
120/208/240V
Transformer Secondary Voltage
24V
Relay Type
DPDT
Primary Connection
Color coded leads - pre stripped
120V FLA Rating
13.8
Secondary Connection
Terminal board with 5 screw terminals
VA Rating
40
120V LRA Rating
82.8
208-240V FLA Rating
6.9
208-240V LRA Rating
41.4
HP Rating
0.75
Item #:
24010
MARS Fan Control Centers
- Provides convenient low voltage control of one and two speed fan motors and auxiliary circuits in heating, cooling, or heating/cooling applications
- Reliable, compact unit consisting of a 24 volt control transformer and a plug-in switching relay mounted on a 4" square electrical junction box cover
- UL 1585 40VA transformer
- Color coded leads
- Low voltage terminal board
Fan Centers
Transformer Primary Voltage
120/208/240V
Transformer Secondary Voltage
24V
Relay Type
DPDT
Primary Connection
Color coded leads - pre stripped
120V FLA Rating
13.8
Secondary Connection
Terminal board with 5 screw terminals
VA Rating
40
120V LRA Rating
82.8
208-240V FLA Rating
6.9
208-240V LRA Rating
41.4
HP Rating
0.75
| MFG Name | MFG # |
|---|---|
| Honeywell | R8239B-1043, R8285B-1053 |
| Packard | FC90130 |
| SUPCO | FC4031 |
| RBM | 90-112 |
| White Rodgers | 90-130, 8A94-51 |
| Zettler | ZC90119 |
Be careful! The information provided is intended to serve as a reference to assist in the selection of products sold by MARS. It is the responsibility of users to validate any cross reference information provided to determine suitability for the intended application. The company is using the competitor's brand names for reference only, and without license or permissions of those companies.
