Home
>
Motors
>
Refrigeration
>
ECM
> AZURE 3.3 COM REFRIG MTR
AZURE 3.3 COM REFRIG MTR
Motor Type
ECM
Enclosure
TEAO
HP (Max.)
1/15-1/25
Voltage
115/230
Mounting
Stud
Speeds
2
Hz
60/50
Rotation
REV
Multi-Rated HP
1/15-1/25
RPM Range
1550/800
NEMA Frame Size
3.3
Phase
Single
Standards
UL
FLA
1.3/0.65
Bearing
Ball
Lead Length (in.)
24
Thermal Protection
Auto
Ambient Deg C
-40 to 55C (-40 to 131F)
Ins. Class
B
Shaft Dia. (in.)
5/16
Capacitor Included
No
Shaft Length (in.)
2.5
Duty
Continuous
Item #:
10850
Azure ECM Commercial Refrigeration
- Walk in Cooler/Freezer Applications
- Drop in 3.3 in. ECM replaces most OEM / ECM / PSC
- Multi-HP, self adjusting from 1/15 to 1/25HP
- Ball Bearing, Reversible
- Auto Voltage Select - 115/230V
- No Capacitor Required
Motors
Motor Type
ECM
Enclosure
TEAO
HP (Max.)
1/15-1/25
Voltage
115/230
Mounting
Stud
Speeds
2
Hz
60/50
Rotation
REV
Multi-Rated HP
1/15-1/25
RPM Range
1550/800
NEMA Frame Size
3.3
Phase
Single
Standards
UL
FLA
1.3/0.65
Bearing
Ball
Lead Length (in.)
24
Thermal Protection
Auto
Ambient Deg C
-40 to 55C (-40 to 131F)
Ins. Class
B
Shaft Dia. (in.)
5/16
Capacitor Included
No
Shaft Length (in.)
2.5
Duty
Continuous
